- Signal Processing
- Digital Signal Processing (DSP)
- Input Bias Current
- -1 µA to 1 µA (ON TIME input; working conditions T = 25 °C, VDD = 3 V unless otherwise specified.)ON TIME input; working conditions T = 25 °C, VDD = 3 V unless otherwise specified.
- Lock Time
- 2.3 s (Working conditions; T = 25 °C, VDD = 3 V unless otherwise specified.)typ · Working conditions; T = 25 °C, VDD = 3 V unless otherwise specified.
- Maximum Pin Current
- -100 mA to 100 mA (Maximum Ratings; current for pin.)Maximum Ratings; current for pin.
- Oscillator Frequency
- 64 kHz (On-chip oscillator; working conditions T = 25 °C, VDD = 3 V unless otherwise specified.)max · On-chip oscillator; working conditions T = 25 °C, VDD = 3 V unless otherwise specified.
- Output High Current
- -10 mA (Output high state; VOH > (VDD - 1 V).)max · Output high state; VOH > (VDD - 1 V).
- Output Low Current
- 10 mA (Output low state; VOL < 1 V.)min · Output low state; VOL < 1 V.
- Optical Window Size
- 4 mm x 3 mm
- Sensitivity
- 100 µV (Working conditions; T = 25 °C, VDD = 3 V unless otherwise specified.)typ · Working conditions; T = 25 °C, VDD = 3 V unless otherwise specified.
- Storage Temperature
- -40 °C to 125 °C (Maximum Ratings; storage.)Maximum Ratings; storage.
- Absolute Maximum Supply Voltage Range
- -0.3 V to 3.6 V (Maximum Ratings; VDD.)Maximum Ratings; VDD.
- On Time Setting Range
- 1.8 s to 3686 s (Digital on-time control settings 0 through 15.)Digital on-time control settings 0 through 15.
