- Display Type
- CCFL
- Output Impedance
- 50 Ωtyp
- Pin Count
- 8
- UVLO Hysteresis
- 0.2 V (Ta = 25 °C)typ · Ta = 25 °C
- Open Lamp Protection Hysteresis
- 50 mV (VDD = 6.0 V; Ta = 25 °C)typ · VDD = 6.0 V; Ta = 25 °C
- Error Amplifier Input Voltage
- 0.75 V to 2.25 V
- Reference Line Regulation
- 20 mV (VDD = 4.5 V to 8.5 V)max · VDD = 4.5 V to 8.5 V
- Open Lamp Detection Enable Threshold
- 2.5 V (VDD = 6.0 V; Ta = 25 °C)typ · VDD = 6.0 V; Ta = 25 °C
- Open Lamp Detection Lower Threshold
- 325 mV (VDD = 6.0 V; Ta = 25 °C)typ · VDD = 6.0 V; Ta = 25 °C
- Error Amplifier Open Loop Gain
- 80 dBtyp
- Maximum Junction Temperature
- 150 °C (Absolute rating)max · Absolute rating
- Reference Voltage
- 1.5 V (Measured at Vin-; VDD = 6.0 V; Ta = 25 °C)typ · Measured at Vin-; VDD = 6.0 V; Ta = 25 °C
- Storage Temperature
- -55 °C to 150 °C
- Error Amplifier Unity Gain Bandwidth
- 1.5 MHztyp
- UVLO Upper Threshold
- 4 V (Ta = 25 °C)typ · Ta = 25 °C
- Absolute Maximum Supply Voltage
- 9 V (Ta = 25 °C)max · Ta = 25 °C
